Switches and Disconnectors

for Loads/Motor Protection

Motor protection and control ensure the service continuity of the power AC motor. In cause of fault, damage to the electrical motor is prevented thanks to constant monitoring of its parts.

Microelettrica provides solutions for different poles configuration and current values, to cover a wide range of needs and safeguard your equipment effectively, extending its life and increasing power systems reliability.

N 125 1NO

Ue  600 V
In  125 A
p  1NO
UC  DC3

N 125 2NO

Ue  1000 V
In  125 A
p  2NO
UC  DC3

N 125 2NO+1NC

Ue  1000 V
In  125 A
p  2NO+1NC
UC  DC3

N 125 3NO

Ue  690 V
In  125 A
p  3NO
UC  AC3

N 190 1NO

Ue  600 V
In  190 A
p  1NO
UC  DC3

N 190 2NO

Ue  1000 V
In  190 A
p  2NO
UC  DC3

N 190 2NO+1NC

Ue  1000 V
In  190 A
p  2NO+1NC
UC  DC3

N 190 3NO

Ue  690 V
In  190 A
p  3NO
UC  AC3

N 350 2NO+1NC

Ue  1000 V
In  350 A
p  2NO+1NC
UC  DC3

N 350 1NO

Ue  600 V
In  350 A
p  1NO
UC  DC3

N 350 2NO

Ue  1000 V
In  350 A
p  2NO
UC  DC3

N 350 3NO

Ue  690 V
In  350 A
p  3NO
UC  AC3

N 650 1NO

Ue  600 V
In  650 A
p  1NO
UC  DC3

N 650 2NO

Ue  1000 V
In  650 A
p  2NO
UC  DC3

N 650 2NO+1NC

Ue  1000 V
In  650 A
p  2NO+1NC
UC  DC3

N 650 3NO

Ue  690 V
In  650 A
p  3NO
UC  AC3

N 1000 1NO

Ue  600 V
In  1000 A
p  1NO
UC  DC3

N 1000 2NO

Ue  1000 V
In  1000 A
p  2NO
UC  DC3

N 1000 2NO+1NC

Ue  1000 V
In  1000 A
p  2NO+1NC
UC  DC3

N 1000 3NO

Ue  690 V
In  1000 A
p  3NO
UC  AC3

N 1250 1NO

Ue  600 V
In  1250 A
p  1NO
UC  DC3

N 1250 2NO

Ue  1000 V
In  1250 A
p  2NO
UC  DC3

N 1250 2NO+1NC

Ue  1000 V
In  1250 A
p  2NO+1NC
UC  DC3

N 1250 3NO

Ue  690 V
In  1250 A
p  3NO
UC  AC3

N 2000 1NO

Ue  600 V
In  2000 A
p  1NO
UC  DC3

N 2000 2NO

Ue  1000 V
In  2000 A
p  2NO
UC  DC3

N 2000 2NO+1NC

Ue  1000 V
In  2000 A
p  2NO+1NC
UC  DC3

N 2000 3NO

Ue  690 V
In  2000 A
p  3NO
UC  AC3

N 3000 1NO

Ue  600 V
In  2500 A
p  1NO
UC  DC3

N 3000 2NO

Ue  1000 V
In  2500 A
p  2NO
UC  DC3

N 3000 2NO+1NC

Ue  1000 V
In  2500 A
p  2NO+1NC
UC  DC3

N 3000 3NO

Ue  690 V
In  2500 A
p  3NO
UC  AC3
PROTECTIVE FUNCTION PACKAGES
F   Standard Feeder (ANSI 50/51, 51BF, 50N/51N, 68, 86)
FF   Advanced Feeder (ANSI 46, 49, 50/51, 51BF, 50N/51N, 68, 79, 86)
V   Standard Voltage (ANSI 27, 59, 81, 68, 86)
VV   Advanced Voltage (ANSI 27, 27V1, 59, 59N, 59V2, 68, 81, 86)
M   Motor (ANSI 37, 46, 48, 49, 51LR, 64, 66, 68, 86)
Dir   Directional (ANSI 67, 67N)
AF   Additional Functions
Note: 68, 86 not present in N-DIN series
TECHNICAL SPECIFICATIONS
Pc  Power Continuous
R  Resistance Range
IP  Protection Class
TECHNICAL SPECIFICATIONS
LWH  Dimensions
Vn  Voltage Class
TECHNICAL SPECIFICATIONS
D  Diameter
P  Power
Pst  Pressure
FC  Fire Class
TECHNICAL SPECIFICATIONS
Ue  Rated Voltage
Ith  Thermal Current
Isc  Short Circuit Making and Breaking Capacity
TECHNICAL SPECIFICATIONS
Ue  Rated Voltage
In  Rated Current
p  Poles Number
UC  Utilization Category
TECHNICAL SPECIFICATIONS
Vcc  Rated Maximum Interrupting Voltage
Icn  Rated Short-circuit Capacity
Icw  Rated Short-time Withstand Current
