Fans

More than 150.000 Comet Fans units are installed worlwide, under severe service conditions and used in critical applications such as refineries, power plants, ships, trains, cement plants and steel mills to name a few.

Our Fans & Blowers range includes an extremely wide variety of materials, arrangements and configurations: one of the largest offers on the fan market. Reliability, energy-saving and low-noise design concepts are part of our DNA and the foundations for the development of every new project.

Typical performance range of our fan types

Explore Fan Applications

All Fan Series

CNX

D  800 – 1600 mm
P  5.5 ÷ 150 kW
Pst  Up to 4000 Pa
ATEX, IECEx

JET

D  900 – 1600 mm
P  15 ÷ 90 kW
FC  F200/F300/F400

ADF

D  1000 – 2500 mm
P  30 ÷ 400 kW
Pst  Up to 2800 Pa
FC  F200/F300/F400

SAF

D  1000 – 2500 mm
P  30 ÷ 400 kW
Pst  Up to 2800 Pa
FC  F200/F300/F400

MAP/P

D  500 – 2200 mm
P  0.55 ÷ 75 kW

MAP/D

D  1500 – 8000 mm
P  1.5 ÷ 250 kW

AFTS

D  2000 – 5000 mm
P  5.5 ÷ 110 kW
Pst  Up to 800 Pa

AFTE

D  800 – 5000 mm
P  1.1 ÷ 90 kW
Pst  Up to 800 Pa

COR

D  280 – 630 mm
P  0.55 ÷ 11 kW
Pst  Up to 2800 Pa

AF

D  400 – 2400 mm
P  0.55 ÷ 110 kW
Pst  Up to 1800 Pa

OR

D  200 – 800 mm
P  0.55 ÷ 75 kW
Pst  Up to 2800 Pa

CF

D  400 – 1120 mm
P  5.5 ÷ 110 kW
Pst  Up to 6000 Pa
ATEX, IECEx

AFH

D  400 – 1400 mm
P  5.5 ÷ 75 kW
Pst  Up to 2800 Pa
ATEX, IECEx
